SS-RID02-VMSP
Compact Dome, Full Surveillance
Small but mighty, the SS-RID02-VMSP is made for tight spots that demand full situational awareness. Its motorized lens and dual alarms make it a standout in its class. Use it in elevators, stairwells, or compact retail zones to monitor smarter—not harder.
Key Features:
Reliable Coverage: 2MP resolution with WDR for stable, clear imaging.
Zoom Like a Pro: 2.8–12mm motorized varifocal lens offers adjustable focus on demand.
Built-In Deterrents: Audible and visual alarms stop intruders in their tracks.
Live Audio Support: Microphone and speaker ensure two-way communication.
Hardware Reset Support: Hassle-free maintenance keeps your system running.
Compact Dome, Full Surveillance
Small but mighty, the SS-RID02-VMSP is made for tight spots that demand full situational awareness. Its motorized lens and dual alarms make it a standout in its class. Use it in elevators, stairwells, or compact retail zones to monitor smarter—not harder.
Key Features:
Reliable Coverage: 2MP resolution with WDR for stable, clear imaging.
Zoom Like a Pro: 2.8–12mm motorized varifocal lens offers adjustable focus on demand.
Built-In Deterrents: Audible and visual alarms stop intruders in their tracks.
Live Audio Support: Microphone and speaker ensure two-way communication.
Hardware Reset Support: Hassle-free maintenance keeps your system running.
Compact Dome, Full Surveillance
Small but mighty, the SS-RID02-VMSP is made for tight spots that demand full situational awareness. Its motorized lens and dual alarms make it a standout in its class. Use it in elevators, stairwells, or compact retail zones to monitor smarter—not harder.
Key Features:
Reliable Coverage: 2MP resolution with WDR for stable, clear imaging.
Zoom Like a Pro: 2.8–12mm motorized varifocal lens offers adjustable focus on demand.
Built-In Deterrents: Audible and visual alarms stop intruders in their tracks.
Live Audio Support: Microphone and speaker ensure two-way communication.
Hardware Reset Support: Hassle-free maintenance keeps your system running.
-
Image Sensor: 1/2.7”
Effective Pixels: 2MP (1920x1080)
Scanning System: Progressive CMOS
Min. Illumination: Color 0.002 Lux @ F1.6(AGC ON); B/W 0 lux @ IR ON
-
Focal Length (Zoom Ratio): 2.8-12mm
Max. Aperture Ratio:F No. 1.8(W) ~ 3.3(T)
Angular Field of View: Horizontal: 101(W)-33(T)°, Vertical: 52(W)-18(T)°, Diagonal: 124(W)-37(T)°
Min. Object Distance: 1.2m
Lens Type: Motorized(Ø14)
-
Type of Light: IR Light
IR Cut Filter: Yes
Light Range: Up to 30m
Backlight Compensation: Off/On (5 Zone)
Wide Dynamic Range: WDR
Digital Noise Reduction: 3D DNR
Motion Detection: Off/On (8 Level)
Image Setting: Full Color Mode/Day Night Mode/Schedule
Privacy Masking: Off/On (4 Zone, Rectangle)
Gain Control: Auto
White Balance: Auto/Manual
Electronic Shutter Speed: 1/5 ~ 1/20000s
On-Board Storage: Micro SD slot, up to 256GB
Alarm IO: 1 Input – 1 Output
Audio: 1 Input – 1 Output
Hardware Reset: Yes
-
Mainstream @60fps: 1080P (1920x1080), 960P (1280x960), 720P (1280x720);
Sub Stream @30fps: 720P (1280x720), VGA (640x480), QVGA (320x240);
Mobile Stream @30fps: VGA (640x480), QVGA (320x240)
-
Ethernet: RJ45(10/100BASE-T)
Video Compression Format: H.265/H.264
Video Quality Adjustment: 256Kbps ~ 8Mbps
Bitrate Control Method: CBR/VBR
Streaming Capability: Triple-Stream (Main/Sub/Mobile)
IP: IPv6
Protocol: TCP/IP, HTTP, DHCP, DNS, DDNS, RTP/RTSP, SMTP, NTP, UPnP, SNMP, HTTPS, FTP
Application Programming Interface: ONVIF (Profile S/G/T)
Web Viewer: IE10/11, Safari V12.1 above, Firefox V.52 above, Google Chrome V.57 above, Edge V.79 above
-
Send Email, FTP Picture and Video Upload
Cloud Picture and Video Upload
Record On NVR and SD Card
Event Push and Alarm Out
IP address filter
HTTPS encryption
Complicated password
Control timeout settings
-
Voltage: D12V/POE(IEEE802.3af), 3.9W/5.7W
Material: Metal
Operating Conditions: -35～+60°C/less than ≤ 95% RH
Storage Conditions: -35～+60°C/less than ≤ 95% RH
Ingress Protection: IP67
ONVIF Conformant: Support Profile (S/G/T)
RTSP Protocol: Supported
-
Face Recognition
Human & Vehicle Detection
Perimeter Intrusion Detection
Line Crossing Detection
Cross Counting
Stationary Object Detection
Heat Map
Crowd Density Detection
Queue Length Detection
License Plate Recognition
Rare Sound Detection
