SS-RIF12-F360

$0.00

All-Around Security, Wall or Ceiling
Whether mounted on a wall or ceiling, this 12MP fisheye camera offers all-seeing, full-circle protection. Ideal for retail spaces, lobbies, or open-plan environments where a single device must cover every angle.

Key Features:

  • Mount It Your Way: Choose between 180° wall-mounted views or 360° ceiling installations for maximum flexibility.

  • Ultra-High Definition: The 12MP fixed lens delivers rich detail that’s perfect for forensic zooming or expansive monitoring.

  • Built-In Alarms: Smart alerts and visual/audible warnings deter threats while keeping teams informed in real-time.

  • Audio-Visual Communication: Mic and speaker functions make it easy to speak and listen remotely for enhanced interactivity and response.

Quantity:
Add To Cart

All-Around Security, Wall or Ceiling
Whether mounted on a wall or ceiling, this 12MP fisheye camera offers all-seeing, full-circle protection. Ideal for retail spaces, lobbies, or open-plan environments where a single device must cover every angle.

Key Features:

  • Mount It Your Way: Choose between 180° wall-mounted views or 360° ceiling installations for maximum flexibility.

  • Ultra-High Definition: The 12MP fixed lens delivers rich detail that’s perfect for forensic zooming or expansive monitoring.

  • Built-In Alarms: Smart alerts and visual/audible warnings deter threats while keeping teams informed in real-time.

  • Audio-Visual Communication: Mic and speaker functions make it easy to speak and listen remotely for enhanced interactivity and response.

All-Around Security, Wall or Ceiling
Whether mounted on a wall or ceiling, this 12MP fisheye camera offers all-seeing, full-circle protection. Ideal for retail spaces, lobbies, or open-plan environments where a single device must cover every angle.

Key Features:

  • Mount It Your Way: Choose between 180° wall-mounted views or 360° ceiling installations for maximum flexibility.

  • Ultra-High Definition: The 12MP fixed lens delivers rich detail that’s perfect for forensic zooming or expansive monitoring.

  • Built-In Alarms: Smart alerts and visual/audible warnings deter threats while keeping teams informed in real-time.

  • Audio-Visual Communication: Mic and speaker functions make it easy to speak and listen remotely for enhanced interactivity and response.

    • Imaging Device: 1/2.3"

    • Effective Pixels: 2 x 5MP (2592x1944)

    • Scanning System: Progressive CMOS

    • Min. Illumination: Color Color 0.01lux @ F1.6(AGC ON); B/W 0 lux @ IR ON

    • Pixel Interval: 12μm

    • Aperture: F 2.0 ±5%

    • Focal Length (Zoom Ratio): 2.8mm

    • Max. Aperture Ratio: F1.0

    • Angular Field of View: Horizontal: 180° Wall Mount, 360° Ceiling Mount

    • Lens Type: Motorized(Ø14)

    • Type of Light: IR Light

    • IR Cut Filter: Yes

    • Light Range: Up to 10m

    • Wide Dynamic Range: DWDR

    • Digital Noise Reduction: BLC, HLC, 3D DNR

    • Motion Detection: Off/On (8 Level)

    • Image Setting: Full Color Mode/Day Night Mode/Schedule

    • Privacy Masking: Off/On (4 Zone, Rectangle)

    • Gain Control: Auto

    • White Balance: Auto/Manual

    • Electronic Shutter Speed: 1/5 ~ 1/20000s

    • On-Board Storage: Micro SD slot, up to 256GB

    • Alarm IO: 1 Input – 1 Output

    • Audio: 1 Input – 1 Output

    • Audio Compression: G.711a/G.711u

    • Hardware Reset: Yes

    • Mainstream @15fps: 4000x3000, @25fps: 3000x3000, 2560x2560, 2160x2160, 1520x1520, 1080x1080, 720x720;

    • Sub Stream @15fps: 1280x960, 640x480, @25fps: 1080x1080, 720x720, 480x480;

    • Mobile Stream @15fps: 640x480, @25fps: 480x480

    • Ethernet: RJ45 10M / 100M

    • Video Compression Format: H.265/H.264/H.265+/H2.64+/MJPEG

    • Video Quality Adjustment: 256Kbps ~ 16Mbps

    • Region Of Interest (ROI): Supported

    • BLC: Supported

    • PoE: Yes

    • Streaming Capability: Triple-Stream (Main/Sub/Mobile)

    • IP: IPv4/IPv6

    • Protocol: TCP/IP, HTTP, DHCP, DNS, DDNS, RTP/RTSP, SMTP, NTP, UPnP, SNMP, HTTPS, FTP

    • Streaming Method: Unicast/ Multicast

    • Application Programming Interface: ONVIF (Profile S/G/T), HTTP API

    • Web Viewer: IE10/11, Safari V12.1 above, Firefox V.52 above, Google Chrome V.57 above, Edge V.79 above

    • Send Email, FTP Picture and Video Upload

    • Cloud Picture and Video Upload

    • Record On NVR and SD Card

    • Event Push and Alarm Out

    • IP address filter

    • HTTPS encryption

    • Complicated password

    • Control timeout settings

    • Voltage: D12V/POE(IEEE802.3af), 3.8W/9.6W

    • Material: Metal

    • Operating Conditions: -35～+60°C/less than ≤ 95% RH

    • Storage Conditions: -35～+60°C/less than ≤ 95% RH

    • Ingress Protection: IP66

    • ONVIF Conformant: Support Profile (S/G/T)

    • RTSP Protocol: Supported

    • Face Recognition

    • Human & Vehicle Detection

    • Perimeter Intrusion Detection

    • Line Crossing Detection

    • Cross Counting

    • Stationary Object Detection

    • Heat Map

    • Crowd Density Detection

    • Queue Length Detection

    • License Plate Recognition

    • Rare Sound Detection

Widen Your Vision with Our AI Cameras

Discover how Scharfe-Sicht’s state-of-the-art cameras combine precision imaging with innovative features like License Plate Recognition (LPR) for enhanced monitoring and safety. Whether for critical infrastructure or everyday security, our solutions offer unmatched clarity, smart deterrence, and real-time control—empowering you to stay one step ahead.

Stay secure with Scharfe-Sicht—because your safety matters.
