SS-RTH05-SDF7
Precision with 7mm Thermal View
When fine thermal detail is a non-negotiable, the SS-RTH05-SDF7 delivers elite performance. This LPR-ready camera features a 7mm thermal lens paired with a visible optical lens, offering a dual-spectrum defense system ideal for critical zones like borders, industrial perimeters, and secured entry points.
Key Features:
Thermal Clarity You Can Trust: Equipped with a 256x192 resolution and 12μm VOx thermal sensor, it offers pinpoint heat detection and exceptional thermal imagery, even in low-visibility or pitch-black scenarios.
Wide Dynamic Range Support: The integrated optical lens features WDR (Wide Dynamic Range) technology, ensuring the visible spectrum remains sharp and balanced no matter the lighting conditions.
Real-Time Communication + Alerts: Built-in microphone and speaker allow for two-way interaction, while integrated alarms provide instant audio-visual response to unusual activity.
Tough and Tactical: Designed for action with hardware reset capabilities and alarm triggers, making it ready for rapid deployments in high-risk environments.
Precision with 7mm Thermal View
When fine thermal detail is a non-negotiable, the SS-RTH05-SDF7 delivers elite performance. This LPR-ready camera features a 7mm thermal lens paired with a visible optical lens, offering a dual-spectrum defense system ideal for critical zones like borders, industrial perimeters, and secured entry points.
Key Features:
Thermal Clarity You Can Trust: Equipped with a 256x192 resolution and 12μm VOx thermal sensor, it offers pinpoint heat detection and exceptional thermal imagery, even in low-visibility or pitch-black scenarios.
Wide Dynamic Range Support: The integrated optical lens features WDR (Wide Dynamic Range) technology, ensuring the visible spectrum remains sharp and balanced no matter the lighting conditions.
Real-Time Communication + Alerts: Built-in microphone and speaker allow for two-way interaction, while integrated alarms provide instant audio-visual response to unusual activity.
Tough and Tactical: Designed for action with hardware reset capabilities and alarm triggers, making it ready for rapid deployments in high-risk environments.
Precision with 7mm Thermal View
When fine thermal detail is a non-negotiable, the SS-RTH05-SDF7 delivers elite performance. This LPR-ready camera features a 7mm thermal lens paired with a visible optical lens, offering a dual-spectrum defense system ideal for critical zones like borders, industrial perimeters, and secured entry points.
Key Features:
Thermal Clarity You Can Trust: Equipped with a 256x192 resolution and 12μm VOx thermal sensor, it offers pinpoint heat detection and exceptional thermal imagery, even in low-visibility or pitch-black scenarios.
Wide Dynamic Range Support: The integrated optical lens features WDR (Wide Dynamic Range) technology, ensuring the visible spectrum remains sharp and balanced no matter the lighting conditions.
Real-Time Communication + Alerts: Built-in microphone and speaker allow for two-way interaction, while integrated alarms provide instant audio-visual response to unusual activity.
Tough and Tactical: Designed for action with hardware reset capabilities and alarm triggers, making it ready for rapid deployments in high-risk environments.
-
Image Sensor: Vanadium Oxide Uncooled Focal Plane Arrays
Max. Resolution: 256×192
Pixel Interval: 12μm
Response Waveband: 8-14μm
NETD (Noise Equivalent Temperature Difference): < 50 mK (25°C, F1.0)
Lens (Focal Length): 3.2mm
IFOV: 3.75 mrad
Field of View: 56°x42°
Aperture: F 1.1
-
Imaging Device: 1/2.7"
Max. Image Resolution: 2592x1944
Scanning System: Progressive CMOS
Min. Illumination: Color: 0.003 Lux @(F1.6, AGC ON), B/W: 0 @IR ON
Lens (Focal Length): 3.6mm
Field of View: Horizontal: 81°, Vertical: 57°, Diagonal: 108°
-
Menu Language: English, Russian, German, Italian, French, Portuguese, Spanish, Turkish, Japanese
Bi-Spectrum Image Fusion: Fusion view of thermal view and overlaid details of the optical channel
IR Viewable Length: Up to 30 m
Day & Night: IR cut filter with auto switch (Day/Night/Auto/Schedule）
Wide Dynamic Range: WDR
Electronic Shutter Speed: 1/5 ~ 1/100000s
On-Board Storage: Micro SD slot, up to 256GB
Alarm IO: 1 Input – 1 Output
Audio: 1 Input – 1 Output
Hardware Reset: Yes
Analog Video Output (BNC): NA
-
Ethernet: 1, RJ45 10M/100M, self-adaptive
Video Compression Format: H.265/H.264/MJPEG
Audio Compression Format: G.711u/G.711a
Streaming Capability: Triple-Stream (Main/Sub/Mobile)
Protocol: TCP/IP, HTTP, DHCP, DNS, DDNS, RTP/RTSP, SMTP, NTP, UPnP, SNMP, HTTPS, FTP
Max. User Access: 10 Users, 2 Levels: Administrator, User
Application Programming Interface: ONVIF (Profile S/G/T)
Web Viewer: IE10/11, Safari V12.1 above, Firefox V.52 above, Google Chrome V.57 above, Edge V.79 above
-
Intelligent Analytics: High sensitivity thermal module with 256×192 resolution, 12 μm, VOx UFPA, NETD < 50 mK (25°C, F1.0)
Temperature Measurement: Global, 12 points, 12 areas and 12 lines; powerful behavior analysis functions, based on deep learning algorithm: PID, LCD, Fire detection, temperature exception alarm
Temperature Range: -15 °C to + 150 °C, (-5 °F to + 302°F); temperature exception alarm for fire prevention, -15°C to 150°C (-5°F to 302°F), ± 8°C (± 14.4°F)
Temperature Accuracy: ± 8 °C (± 14.4 °F); dynamic fire point detection
Fire Detection: Dynamic fire point detection; image processing technology: linear, histogram, self-adaptive thermal AGC mode, DDE, 3D DNR
-
Voltage: 12 VDC ± 20%, PoE (802.3af)
Material: Metal
Operating Conditions: -30 °C to 60 °C (-22 °F to 140 °F)
Humidity: 90% or less
Ingress Protection: IP66
Environment: RoHS2.0
-
Face Recognition
Human & Vehicle Detection
Perimeter Intrusion Detection
Line Crossing Detection
Cross Counting
Stationary Object Detection
Heat Map
Crowd Density Detection
Queue Length Detection
License Plate Recognition
Rare Sound Detection
