SS-RIB05-ESVM
Built to Watch, Designed to Perform
When you need long-range visibility in an outdoor setting, this 5MP bullet camera is the solution. Built to withstand tough environments, it pairs high-definition visuals with audio features and motorized zoom.
Key Features:
5MP Performance: Crisp imaging for perimeter, entryway, or open space surveillance.
Adjust to Your View: Motorized 2.8–12mm lens gives you range and flexibility.
Round-the-Clock Surveillance: Automatic IR lets you monitor even in low light.
Talk + Listen: Integrated mic and speaker keep you in control of interactions.
Easy Fixes: Hardware reset keeps downtime minimal.
Built to Watch, Designed to Perform
When you need long-range visibility in an outdoor setting, this 5MP bullet camera is the solution. Built to withstand tough environments, it pairs high-definition visuals with audio features and motorized zoom.
Key Features:
5MP Performance: Crisp imaging for perimeter, entryway, or open space surveillance.
Adjust to Your View: Motorized 2.8–12mm lens gives you range and flexibility.
Round-the-Clock Surveillance: Automatic IR lets you monitor even in low light.
Talk + Listen: Integrated mic and speaker keep you in control of interactions.
Easy Fixes: Hardware reset keeps downtime minimal.
Built to Watch, Designed to Perform
When you need long-range visibility in an outdoor setting, this 5MP bullet camera is the solution. Built to withstand tough environments, it pairs high-definition visuals with audio features and motorized zoom.
Key Features:
5MP Performance: Crisp imaging for perimeter, entryway, or open space surveillance.
Adjust to Your View: Motorized 2.8–12mm lens gives you range and flexibility.
Round-the-Clock Surveillance: Automatic IR lets you monitor even in low light.
Talk + Listen: Integrated mic and speaker keep you in control of interactions.
Easy Fixes: Hardware reset keeps downtime minimal.
-
Imaging Device: 1/2.7” SC500AI sensor
Effective Pixels: 5MP (2880x1620)
Scanning System: Progressive CMOS
Min. Illumination: Color 0.004lux @ F1.6(AGC ON); B/W 0 lux @ IR ON
-
Focal Length (Zoom Ratio): 2.8-12mm
Max. Aperture Ratio: F No. 1.8
Angular Field of View: Horizontal: 107(W)-34(T)°, Vertical: 55(W)-19(T)°, Diagonal: 134(W)-38(T)°
Min. Object Distance: 0.2m
Lens Type: Motorized(Ø14)
-
Type of Light: IR Light
IR Cut Filter: Yes
Light Range: Up to 45m
Backlight Compensation: Off/On (5 Zone)
Wide Dynamic Range: 100 dB
Digital Noise Reduction: 3D DNR
Motion Detection: Off/On (8 Level)
Image Setting: Full Color Mode/Day Night Mode/Schedule
Privacy Masking: Off/On (4 Zone, Rectangle)
Gain Control: Auto
White Balance: Auto/Manual
Electronic Shutter Speed: 1/5 ~ 1/20000s
On-Board Storage: Micro SD slot, up to 256GB
Alarm IO: NA
Audio: 1 Input – 1 Output
Hardware Reset: Yes
-
Mainstream @30fps: 5MP (2880x1620), 4MP (2592x1520), 3MP (2304x1296), 1080P (1920x1080), 960P (1280x960), 720P (1280x720);
Sub Stream @30fps: 720P (1280x720), VGA (640x480), QVGA (320x240);
Mobile Stream @30fps: VGA (640x480), QVGA (320x240)
-
Ethernet: RJ45(10/100BASE-T)
Video Compression Format: H.265+/H.265/H.264+/H.264
Video Quality Adjustment: 256Kbps ~ 8Mbps
Bitrate Control Method: CBR/VBR
IP: IPv6/IPv4
Protocol: TCP/IP, HTTP, DHCP, DNS, DDNS, RTP/RTSP, SMTP, NTP, UPnP, SNMP, HTTPS, FTP
Streaming Method: Unicast/Multicast
Application Programming Interface: ONVIF (Profile S/G/T)
-
Model: NT98525, Features a Quad-core ARM Cortex-A53 CPU, A Mali-G52 GPU, and a dedicated video processing unit (VPU), High-performance hardware DLA module, graphics engine
-
Send Email, FTP Picture and Video Upload
Cloud Picture and Video Upload
Record On NVR and SD Card
Event Push and Alarm Out
IP address filter
HTTPS encryption
Complicated password
Control timeout settings
-
Voltage: D12V/POE(IEEE802.3af), 7W/9W
Material: Metal
Operating Conditions: -35～+60°C/less than ≤ 95% RH
Storage Conditions: -35～+60°C/less than ≤ 95% RH
Ingress Protection: IP67
ONVIF Conformant: Support Profile (S/G/T)
RTSP Protocol: Supported
-
Face Recognition
Human & Vehicle Detection
Perimeter Intrusion Detection
Line Crossing Detection
Cross Counting
Stationary Object Detection
Heat Map
Crowd Density Detection
Queue Length Detection
License Plate Recognition
Rare Sound Detection
